제품 상세 정보:
|
| 이름: | 웜 엣지 스페이서 밴더 기계 | 최소한도 구부리는 크기: | 200*300mm |
|---|---|---|---|
| 알루미늄 간격 장치 폭: | 6A-27A | 구부리는 크기 과실: | ±0.5mm |
| 각 과실: | ±1 | 공기 Suplier: | 0.65Mpa |
| 총 힘: | 2.5KW | 차원: | 1000*2200*2600mm |
| MAX: | 2500*2500mm | 상태: | 새롭습니다 |
| 강조하다: | Folding Windows Spacer Bending Machine,Doors Frame Spacer Bending Machine,Doors Frame glass bending equipment |
||
• Germany Siemens PLC control system, touch screen interface • Japan FUJI CNC servo control system • Four spacer size storage units • Using servo system to control feeding mechanism • Automatically cut and feed aluminum spacers • Auxiliary function of adjustment for bending large aluminum frame • Aluminum spacers are available in different sizes and sizes • Bend shaped spacer frames continuously • Separated guard board outside of bender • Automatically avoid the connection while bending and cutting • Pause and Reset device for handling equipment failures • Can bend aluminum spacer, Technoform, Alupro, Thermix, warm spacer (Swisspacer).
Spacer Bending machine main components
| NAME | BRAND |
| PLC | GERMAN SIEMENS |
| Low voltage electrical apparatus | GERMAN SIEMENS |
| Servo motor | GERMAN SIEMENS |
| Servo driver | GERMAN SIEMENS |
| Relay | JAPAN OMRON |
| Triplet | Taiwan AIRTAC |
| Cylinder | Taiwan AIRTAC |
| TOUCH SCREEN | Taiwan WEINVIEW |
| Switch power | Taiwan TEND |
| GUIDE | Taiwan TBI |
| Solenoid valve | Taiwan AIRTAC |
| Sensor | KOREA AUTONICS |
Main technical parameter
| Max.bending size | 2000mm*2000mm |
| Min.bending size | 250mm*200mm |
| Aluminum spacer width | 5.5-24mm |
| Dimensional error: | ≤±0.5mm |
| Angle error | ≤±1º |
| Processing speed | ≤26s |
| Air supply | ≥0.65MPa |
| Total power | AC220/380V 50Hz 2.5KW |
| Dimension | 10500mm*2200mm*2600mm |
Until 2019, we exported glass machines and materials to America, South America, Europe, the Middle East, India and so on, nearly 30 countries and regions. We have established a perfect international business relationship with 10 powerful agents and made an endeavor together to build a famous international brand to the world. Kation-Tech, with craftsmanship, profession and honesty, wins the future with you together!
